No need to required stone balancing and maintenance.
Diamond cutter Emery stone use long time long life.
Moving ease and operate smooth and easy system.
use domestic & commercial power supply.
2.25" X 14" inch stone PAIR size.
Flouring capacity depends on electric motor.
Operate 3 HP single Phase (Lubi) motor.
Domestic & Commercial use.
After milling No need to clean.
4 TO 8 WORKING DAYS
No need to required stone balancing and maintenance.
Diamond cutter Emery stone use long time long life.
Moving ease and operate smooth and easy system.
use domestic & commercial power supply.
2.25" X 14" inch stone PAIR size.
Flouring capacity depends on electric motor.
Operate 3 HP single Phase (Lubi) motor.
Domestic & Commercial use.
After milling No need to clean.
DELIVERY TIME : 4 TO 8 WORKING DAYS
| Stone Size | 350 X 27 X 50.80 |
|---|---|
| Flouring Capacity | 30 TO 35 KG PER HRS |
| Basic Plating | Chrome Plated, Coating |
| Body Size | 37" HIGHT X 12" WIDTH |
| Net Weight (KG) Widhoute motor | 100 to 105 kg approx |
| Shafting | 35MM EN8D WITH TEMPERING (HARD) |
| Matrial of Construction (content) | Mild Steel |
| Hopper / Container Capacity (KG) | 15 TO 19 Kg |
| Electrical Data | 3HP, Single phase AC motor, 50 Hz |
| Motor Speed (RPM) | 1440 RPM |
| V Belt Drive | Double ( A Section) |
| Power Consumption | 2.30KWH |
| Certification | CE & ISO |
| Voltage | 220 V |
